Seneca VFX 9100 Workstation
Broadcast

Seneca VFX 9100 Workstation

Creative Computing Redefined.

  • 8th gen Intel® Core™ Processor Family
  • Digital Painting/Illustration, Textures/Photo Manipulation, CAD
  • Dual Full-height, full-length, double-width graphics card options
  • Micro ATX form factor
  • Quiet and cool design
Solution

Broadcast

Harness the power of workstation class components within a micro-tower form factor and what you have is the Seneca VFX 9100 series micro-workstation. Features like liquid cooling, an overclocked 8th generation Intel® Core™ processor and dual GPUs aren’t what you would expect from a small desktop PC, yet the Seneca VFX 9100 delivers just that. Imagine having the power of a sports car and the look of a luxury vehicle, but with the affordability of a compact. Whether you are a freelance artist, a hobbyist or a professional designer, the Seneca VFX 9100 platform empowers you to meet the demands of your workflow while also meeting the requirements of your budget.

Related Resources

Key Features

  • 8th gen Intel® Core™ Processor Family
  • Micro ATX form factor
  • Dual Full-height, full-length, double-width graphics card options
  • Quiet & Cool design
  • Custom performance enhancing BIOS
  • Tuned OS and Balanced drivers for maximum stability
  • 5 year hardware warranty
  • Internal validation to leading ISVs specifications
corei_8gen

8th gen Intel® Core™ Processor Family

Contact Us

Call to speak to a product specialist

800.227.3432

Specifications

System

Mechanicals

Scroll For More

Processor 8th gen Intel® Core™ Processor Family
Operating System Windows 10 Pro
Chipset Intel® Z370
Memory 4 x DDR4; Maximum 64GB
Optical Drive NA
Connectivity Intel® I219V, Dual interconnect between the Integrated Media Access Controller (MAC) and Physical Layer (PHY)
Wi-Fi 802.11 a/b/g/n/ac
Bluetooth V4.2
Graphics

Integrated Intel® HD Graphics 630
2 x Discrete Graphics Card Option

  • NVIDIA® Quadro® P6000
  • NVIDIA® Quadro® P5000
  • NVIDIA® Quadro® P4000
  • NVIDIA® Quadro® P2000
  • NVIDIA® Quadro® P1000
  • NVIDIA® Quadro® P600
  • AMD® FirePro™ W9100
  • AMD® FirePro™ W8100
  • AMD® FirePro™ WX7100
  • AMD® FirePro™ WX5100
  • AMD® FirePro™ WX4100
Supported Displays Up to 15 with discrete/integrated GPU combination
Audio ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
USB 2 x USB 3.1 Gen 2 Type-A (back, red)
4 x USB 3.1 Gen 1 (back, blue)
2 x USB 2.0
Expandability 1 x RJ45
1 x PS/2
5 x Audio Jacks
1 x DisplayPort
1 x HDMI
1 x Optical S/PDIF Out
Expansion Slot 2 x PCIe 3.0/2.0 x16 (x16 or dual x8)
2 x PCIe 3.0/2.0 x1
Warranty 5 Year Hardware Warranty with Next Day Business Replacement
Form Factor Micro ATX
Power Supply 860W PSU 80+ Platinum
Power Draw NA
Cooling 1 x 120mm (back)
1 x 120mm or 2 x 120mm; Optional front and/or top
Bays 1 x 5.25” OOD
2 x 3.5″
3 x 2.5″ mounts
Front Interface 1 x USB 3.0
1 x USB 2.0
Audio In/Out
Dimensions (w x h x d) 7.125 x 14.25 x 16.378 in / 181 x 362 x 416 mm
7.625 x 14.25 x 16.77 in / 194 x 378 x 426 mm with feet and protrusions
Weight 7.5 lbs / 3.4 kg chassis
