Network Video Recorders
ENVY-R 50/100 Series
- Intel® Core™ Processor Technology
- Intel Quick Sync Video application
- Up to 64TB of video storage
- Maestro optimization tool for streamlined setup
- Includes xConnect Core
Solution
Key Features
- Easy system installation
- Cost-effective performance
- Optimized for leading VMS
xConnect Core
The Seneca ENVY-R 50/100 series comes with xConnect Core pre-installed designed to monitor, notify, and manage the environment and performance of your server hardware.
Specifications
System
Mechanicals
Scroll For More
| SQ50 | SQ100 | |
| Processor | Intel® Pentium or Core™ i3 | Intel® Core™ i-series |
| Operating System | Windows 10 IoT | Windows 10 IoT |
| Manufacturer | Seneca | Seneca |
| Memory | Up to 16GB DDR4 2666MHz | Up to 16GB DDR4 2666MHz |
| OS Storage | 1x 256GB SSD | 1x 256GB SSD |
| Raw Storage | Up to 32TB | Up to 32TB in Tower; 64TB in Rack mount |
| Video Outputs | 1 x VGA 1 x DVI-D 1 x DisplayPort 1 x HDMI |
1 x HDMI 1 x DVI/D 1 x VGA |
| Graphics | Intel UHD Graphics 630 with Intel Quick Sync Video | Discrete GPU option available (SQ100) |
| Networking | Dual GbE LAN | Dual GbE LAN |
| USB | 2x USB 3.0; 2x USB 2.0 | Rackmount: Front: 2 x USB 2.0 Tower: Front: 1 x USB 3.0; 1 x USB 2.0 Both: Rear: 2 x USB 3.1 Gen 1; 4 x USB 2.0/1.1 |
| Hardware Monitoring | Pre-Installed with Seneca xConnect Core | Pre-Installed with Seneca xConnect Core |
| Warranty | 3 Year Next Day, On-site Warranty Standard, Keep your Hard Drive Option | 3 Year Next Day, On-site Warranty Standard, Keep your Hard Drive Option |
| Form Factor | Desktop | Tower | 2U Rackmount |
| OS Drive Bays | 256 GB SSD | 256 GB SSD | 256 GB SSD |
| Data Drive Bays | 2 x 3.5″ | 2 x 3.5″ | 4 x 3.5″ |
| Power Supply | 300W | 350W 80+ Bronze | 350W 80+ Bronze |
| Dimensions (w x h x d) | 13 x 3.8 x 14.4in 330 x 96 x 410 mm |
8 x 13.5 x 18.25 in 203.2 x 342.9 x 463.6 mm |
16.9 x 3.5 x 18 in 429.3 x 88.9 x 457.2 mm |
| Weight | 20 lb / 9.07 kg | 21 lb / 9.51kg | 32 lb / 14.5 kg |
