Seneca VFX 9000 Workstation
Big Performance in a Small Package.
- 7th generation Intel® Core™ i7 Processor
- Print, Multimedia, and Basic CAD
- Full-height, full-length, double-width graphics card options
- Small form factor chassis
- Quiet and cool design
Solution
Key Features
- 7th generation Intel® Core™ i7 Processor
- Small form factor chassis
- Quiet & Cool design
- Custom performance enhancing BIOS
- Tuned OS and Balanced drivers for maximum stability
- Full-height, full-length, double-width graphics card options
- 5 year hardware warranty
- Internal validation to leading ISVs specifications
7th gen Intel® Core™ i7 Processor
Specifications
System
Mechanicals
Scroll For More
| Processor | 7th gen Intel® Core™ i7-7700 Processor |
| Operating System | Windows 10 Pro |
| Chipset | Intel® H270 |
| Memory | DDR4-2133MHz |
| Storage | Up to 4.5TB |
| Optical Drive | NA |
| Connectivity | 2 x Killer E2500 Gigabit LAN 802.11 a/b/g/n |
| Graphics |
Integrated Intel® HD Graphics 630
|
| Supported Displays | Up to 7 with discrete/integrated GPU combination |
| Audio | Realtek® ALC1220 HD 7.1 Audio, S/PDIF |
| USB | 1 x USB Type-C with USB 3.1 Gen1 support (Back) 4 x USB 3.1 Gen 2 Type A (Back) 2 x USB 2.0 (2 Front) |
| Expandability | 2 x RJ45 1 x PS/2 5 x Audio Jacks 2 x SMA Antenna (WIFI) 1 x DVI-D 2 x HDMI 1 x Optical S/PDIF |
| Expansion Slot | 1 x PCI Express x16 slot, running at x16 (PCIEX16 slot conforms to PCI Express 3.0 standard) 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI) Warranty |
| Warranty | 5 Year Hardware Warranty with Next Day Business Replacement |
| Form Factor | Small Form Factor |
| Power Supply | 450W SFX 80+ Bronze |
| Power Draw | ErP Compliant (<0.5W system power draw) |
| Front Interface | 2 x USB 3.0/2.0 Audio In/Out Power button with LED (blue) |
| Dimensions (w x h x d) | 14.8 x 3.4 x 13 inches / 376 x 86 x 330 millimeters |
| Weight | 9.5 lbs / 4.3 kg system 17.5 lbs / 7.9 kg packaged box |
